Wake-on-LAN with Powershell

A few weeks ago I wrote about my 4-node IKEA Besta server cluster. To preserve energy, I turn the nodes only on when I need the capacity. This is also good for our energy bill, I do not know how long I can persuade my wife that her hairdryer is responsible for all the electricity costs.



Anyway, I use a PowerShell script to send the Wake-On-LAN magic packet to the network card of the selected server. If you want to read more about the Wake-On-LAN functionality, see this Wikipedia article.

function Send-WOL

{

<#

.SYNOPSIS

Send a WOL packet to a broadcast address

.PARAMETER mac

The MAC address of the device that need to wake up

.PARAMETER ip

The IP address where the WOL packet will be sent to

.EXAMPLE

Send-WOL -mac 00:11:22:33:44:55 -ip 192.168.2.100

#>

[CmdletBinding()]

param(

[Parameter(Mandatory=$True,Position=1)]

[string]$mac,

[string]$ip="255.255.255.255",

[int]$port=9

)

$broadcast = [Net.IPAddress]::Parse($ip)

$mac=(($mac.replace(":","")).replace("-","")).replace(".","")

$target=0,2,4,6,8,10 | % {[convert]::ToByte($mac.substring($_,2),16)}

$packet = (,[byte]255 * 6) + ($target * 16)

$UDPclient = new-Object System.Net.Sockets.UdpClient

$UDPclient.Connect($broadcast,$port)

[void]$UDPclient.Send($packet, 102)

}

send-WOL -mac 00-11-22-33-44-55 -ip 192.168.2.100


In order to function correctly, be sure the server BIOS Power Management EuP 2013 settings are set to disabled and in the Wake Up Event Setup configuration the Resume by Onboard LAN is enabled. Also on your hypervisor, be sure you enable Wake-On-LAN on your properties of the network card.
